INFORMATION DETAILS
ID: 15230758
|
Year: 2019
|
Make: Horst
|
Model: 325 (18 Ton)
|
Type: New
|
| MSRP:
N/A |
Engine Size - cc: N/A |
| Capacity: | 36,000 lbs. |
| Spindles: | 3'' Diameter, C1045 Cold Rolled |
| Hubs: | 8 Stud 12,000 lbs. |
| Bearings : | Taper Roller (2.165 / 1.625) |
| Front Axle: | 8 x 3.5 x .250 Wall |
| Rear Axle: | 8 x 4 x .250 Wall |
| Tongue Bracket Mounting: | 1-1/2'' Bolt Bearing Mtd. |
| Tongue Bolt: | 1-1/8'' Diameter |
| Tongue Latch: | Retractable Automatic Relock |
| Reach Poles: | 3" O.D. x .188 Wall - Round Tube |
| Bolster Stakes: | 42.5'' Fixed |
| Steering: | Automotive Type |
| Tie Rod Ends: | Greasable Automotive Style Ball Joints |
| Wheel Base: | Adjustable |
| Height From Ground To Top of Bunk: | 30'' (11 x 22.5 Tires) |
| Approx Weight: | 1,495 lbs. (less rims and tires) |
| Bearings - Bore Size (Inner/Outer): | Taper Roller (2.165 / 1.625) |
SELLER DESCRIPTION
|
6 Wheel Model
|
-
14 ton tandem wagon gear
-
Quick hitch tongue
-
Standard reach length 11'
-
Wheel Base adjustable 8' 8" - 11' 2"
-
Hubs - 8 Bolt 6,500 LBS.
|
|
Rim & Tire Sizes
|
|
|
|
Tire Size |
Tire Type |
Rim Size |
Track Width |
Capacity
(LBS/Set of 6 Tires)
|
|
14L x 16.1 |
12 Ply |
16.1 x W11C x 8 |
89" |
28,080 |
|
16.5 x 16.1 |
10 Ply |
16.1 x W14C x 8 |
93" |
31,200 |
|
19L x 16.1 |
10 Ply |
16.1 x W16C x 8 |
95" |
36,000 |
|
21.5 x 16.1 |
14 Ply |
16.1 x W16C x 8 |
95" |
36,000 |
|
11 x 22.5 |
Used Truck* |
22.5 x 8.25 x 8 HD |
89" |
36,000 |
|
11 x 22.5 |
New Recap |
22.5 x 8.25 x 8 HD |
89" |
36,000 |
|
12 or 315 x 22.5 |
Used Truck* |
22.5 x 8.25 x 8 HD |
89" |
36,000 |
|
12 or 315 x 22.5 |
New Recap |
22.5 x 8.25 x 8 HD |
89" |
36,000 |
|
305 x 22.5 |
Used Truck* |
22.5 x 8.25 x 8 HD |
89" |
36,000 |
|
305 x 22.5 |
New Recap |
22.5 x 8.25 x 8 HD |
89" |
36,000 |
|
385 x 22.5 |
Used Truck* |
22.5 x 11.75 x 8 |
87" |
36,000 |
|
385 x 22.5 |
New Recap |
22.5 x 11.75 x 8 |
87" |
36,000 |
|
425 x 22.5 |
Used Truck* |
22.5 x 11.75 x 8 |
87" |
36,000 |
|
425 x 22.5 |
New Recap |
22.5 x 11.75 x 8 |
87" |
36,000 |
|
425 x 22.5 |
New Truck |
22.5 x 11.75 x 8 |
87" |
36,000 |
|
425 x 22.5 |
Used Truck |
22.5 x 13 x 8 |
86" |
36,000 |
|
425 x 22.5 |
New Recap |
22.5 x 13 x 8 |
86" |
36,000 |
|
425 x 22.5 |
New Truck |
22.5 x 13 x 8 |
86" |
36,000 |
|
445 x 22.5 |
New Recap |
22.5 x 13 x 8 |
86" |
36,000 |
|
445 x 22.5 |
New Truck |
22.5 x 13 x 8 |
86" |
36,000 |
|
400/55 x 22.5 |
16 Ply |
22.5 x 13 x 8 |
86" |
36,000 |
|
