INFORMATION DETAILS
ID: 13613688
|
Year: 2017
|
Make: H&S
|
Model: HDNR Rear Unload
|
Type: New
|
| MSRP:
N/A |
Engine Size - cc: N/A |
SELLER DESCRIPTION
REAR UNLOAD POWER BOX FEATURES:
-
Rear Unload Power Boxes are available in 18' and 20' models.
-
The heavy duty tailgate is constructed to stand up to the pounding of heavy loads. High pivot points assure crop clearance while unloading.
-
The H&S Power Box is hydraulically driven. Unload time is dependent on tractor R.P.M., hydraulic pressure, and G.P.M.
HDNR REAR UNLOAD POWER BOX FEATURES:
-
HDNR Rear Unload Power Boxes are available in 18' or 20' models.
-
The Power Box utilizes a two-hose hydraulic system to run the main apron. The hydraulic hoses are easily stored in the holder at the front of the box.
-
The Power Box features a chain reduction system instead of a worm gearbox for better efficiency.
-
All HDNR Power Boxes feature Cross Z-iron that is welded to the side channels in-line with stakes for added strength.
|
|
Specifications
|
|
HDNR POWER BOX |
18' |
20' |
|
INSIDE WIDTH |
7'4" |
7'4" |
|
OVERALL LENGTH |
19'6" |
21'6" |
|
OVERALL WIDTH |
104" |
104" |
|
STANDARD BOX OVERALL HEIGHT |
101" |
101" |
|
STANDARD BOX CAPACITY STUCK LEVEL |
950 cu. ft. |
1056 cu. ft |
|
WEIGHT – STANDARD BOX |
6650# |
7110# |
|
MAIN APRON CHAIN |
667H PINTLE CHAIN IS STANDARD, T-ROD,667X OR 667XH PINTLE CHAIN ARE OPTIONAL |
|
MAIN APRON DRIVE |
CHOICE OF HYDRAULIC DRIVE OR P.T.O. DRIVE |
|
UNLOAD SPEED |
UNLOAD TIME IS DEPENDENT ON TRACTOR R.P.M., HYDRAULIC PRESSURE AND G.P.M. |
|
REAR ENDGATE |
AUTOMATIC LOCK AND UNLOCK |
|
ROOF |
OPTIONAL |
OPTIONAL |
|
REAR GATE DELAY |
OPTIONAL |
OPTIONAL |
|
H&S POWER BOX |
18' |
20' |
|
CAPACITY W/ROOF |
994 FT |
1106 FT |
|
INSIDE WIDTH |
7'4" |
7'4" |
|
OVERALL LENGTH |
19'6" |
21'6" |
|
OVERALL WIDTH |
104" |
104" |
|
OVERALL HEIGHT |
118" |
118" |
|
WEIGHT |
3650# |
4050# |
|
